311D

311D

Model 311D
Type Compactor with smooth drum
Operating weight with sunroof 11 220 kg
Drum width 2 140 mm
Emission standard BS III
Brand Hamm
Country of Manufacture India
Location Viet Nam
Contact 0906 702 060 (Mr Tuyen)




HAMM- 100 YEARS OF INNOVATION & EXPERIENCE



hamm 311D



It was in 1911 when Hamm developed the first road compaction equipment with a diesel engine since then our innovative team has been designing trend setting machinery. Today, HAMM is the world‘s major producer of asphalt rollers and soil compactors.



HAMM is famous worldwide for powerful and user-friendly compaction machines for a wide variety of jobs associated with road construction and earth works. Moreover, Hamm rollers are convincing because of their ergonomic and innovative design. HAMM has been awarded a total of 20 design prizes for all its innovations.



Hamm compactor 311D is one of the most typical products of Wirtgen India, a 100% subsidiary of the Wirtgen Group, has maintained a strong presence in India since 1995, with 22 local Sales and Service offices.



Because of the perfect combination of factors such as: strong operation, user friendliness, fast, optimal compacting ability but extremely reasonable price. And most of all, besides bringing many economic benefits to the business, soil compactor 311D has many other values such as fuel saving, construction and environmental protection.



We offer a broad range of services in all areas of road construction and refurbishment. With passion and dedication our highly motivated team ensures your success at the construction site.



Market leading products and top service with tried and tested quality standards give you the confidence you need in your fiercely competitive environment. The Wirtgen Group’s successful brands of long standing will safely keep you on the road to success.



TECHNICAL DATA



Xe lu Hamm 311D
    311D
WEIGHTS
Operating weight with sunroof kg 11 220
Operating weight, max. kg 11 440
Axle load, front / rear kg 6 420 / 4 800
Static linear load, front kg/cm 30.0
French classific., data/class   40.6 / VM3
Xe lu Hamm 311D
MACHINE DIMENSIONS
Total length (L) mm 5 698
Total height (H) mm 3 126
Height, loading, min. (HI) mm 2 331
Wheelbase mm 2 995
Total width (B) mm 2 262
Ground clearance, center mm 419
Turning radius, inside mm 3 990
Angle of driving slope, front / rear ° 29 / 26
DRUM DIMENSIONS
Drum width, front (X) mm 2 140
Drum diameter, front mm 1 504
Drum thickness, front mm 25
Drum type, front   Smooth
WHEEL DIMENSIONS
Size of tires, rear   AW 23.1 - 26 8 PR
DIESEL ENGINE
Manufacturer   CUMMINS
Type   4BT AA 3.9
Number of cylinders    4
Power rat. ISO 14396,  kW/PS/rpm 74 / 100 / 2200
Power rating SAE J1349 kW/PS/rpm 74 / 99 / 2200
Emission standard   BS III
DRIVE
Speed, working gear km/h 0 - 5.5 / 0 - 7.0 / 0 - 8.5
Speed, transportation gear km/h 0 - 12.5
Climbing ability, vibration on/off % 48 / 53
VIBRATION
Vibration frequency, front, I/II Hz 32 / 40
Amplitude, front, I/II mm 1.83 / 0.77
Centrifugal force, front, I/II kN 240 / 158
STEERING
Oscillation angle +/- ° 10
Steering, type   Articulated steering
TANK CAPACITY / FILL CAPACITY
Fuel tank, capacity L 290
SOUND LEVEL
Acoustic power LW(A), sticker db(A) -
Acoustic power LW(A), measured db(A) 110



EQUIPMENTS



Note: standard or optional equipment for Hamm 311D depends on the standard of each country. Please contact us for the answer.



STANDARD: Dashboard with displays, indicator lights and switches, Operator's platform with access on one side, Vibration-isolated operator’s platform, Longitudinal adjustment, 1 drive lever, Tiltable hood, Hydrostatic steering, 3-point articulation, Adjustable scraper, Plastic protective roof, reinforced with fiber glass and foldable, Dashboard cover.



OPTIONAL: HAMM Compaction Meter (HCM), Speedometer, Telematics interface, Working light, Hose protection.



HIGHLIGHTS



Xe lu Hamm 311P



- Sunshade and rain canopy as standard equipment for more comfort.



- Vibration-isolated operator’s platform with a comfortable, individually adjustable driver’s seat. Agile roller with direct steering means less steering work for the operator.



- Outstanding off-road mobility, absorbs shocks. Unrivalled driving stability, high resistance to tipping and top-class directional stability made for safe maneuvering even on rough terrain.



- Robust, water-cooled 4-cylinder engines. Comply with the requirements of CEV BS III. Highly fuel efficient, has a low noise level and provides environmentally friendly operation. Supplementary fuel filter cum water seperator.



- Safety alarm and indication of high cooling water temperature in event of low lubricant oil pressure.



- Efficient oil and water cooling. The volume flow of cooling air adapts to the required cooling capacity. This reduces both power consumption and noise emissions.



- All daily maintenance points are located in readily accessible positions on the same side of the machine – the most important prerequisite for fast checks.



- Operator’s display designed with clear symbols ensures easy operation, comprehensibly shows the state of the machine and indicates fault signals. Machine equipped with cover to prevent vandalism as part of standard scope of supply.



- Large capacity fuel tank permits longer operation and fewer refueling stops.



- Two frequencies enable wide variety of soil to be compacted.



- Front and rear working lights and a tail lamp ensure optimum sight and visibility, even at night time or when working under poor lighting conditions.



Xe lu Hamm 311D



- As a customized solution, 311D compactor can be equipped with or without drum drive. We offer a wide range of drums - Available with smooth drum and with padfoot drum. Drum module is designed to induce high static linear loads of up to 38.3 kg/cm, depending on type of drum.



- Optimum design of air duct facilitates effective engine cooling without heating up the operator’s platform, even at an ambient temperature of up to 55°C.



- Dual scraper bars for smooth working conditions in both forward and reverse direction of operation are part of the standard scope of supply.



- HAMM Compaction Measurement for quick information on compaction results. Shows weak zones and helps to prevent extra passes. (Option).



- Option. ICS minimizes the number of passes, records the output and prevents the danger of over compaction.



DURABLE ENGINE TECHNOLOGY



Xe lu Hamm 311P



The compactors Hamm 311D are true classics for earth work because they combine modern design with proven engineering. They put their capabilities to the test day in, day out, in every corner of the world.



One of their outstanding features is their climbing ability. Depending on the model and configuration, they can scale inclines up to 54 % (drum drive), compacting extremely efficiently as they go.



EFFICIENT AND ECONOMICAL



Robust 4-cylinder Cummins diesel engines in 311D compactors provides ample power with which to drive all components. At the same time, they have adequate reserves for efficient compaction, even under extreme conditions. They comply with the CEV BS III requirements – that means low exhaust emissions and low fuel consumption.



Intelligent airflow enables the rollers to be operated even in high ambient temperatures. A supplementary fuel filter can also be installed. It eliminates excess water from the diesel fuel, ensuring reliable operation



MASTERING EVERY SLOPE



Xe lu Hamm 311P



Great compaction performance



Hamm 311D bring enormous compaction force to the construction site. Their static linear load is every bit as impressive as their centrifugal force.



Not forgetting that the compactors can even master slopes up to 54 % (drum drive) effortlessly.



Ingenious power train concept provides a climbing ability in excess up to 54 % (drum drive).



- The rear axle with limited slip differential prevents wheelspin.



- The 3-point articulation ensures uniform weight distribution between the front and rear sections and thus outstanding traction even in rough terrain.



Xe lu Hamm 311P



The HAMM 3-point articulation is the key to an exceptionally favourable weight distribution, enormous driving stability and supreme traction.



Optimum handling characteristics



The benefits of the 3-point articulation can be seen every day in many situations on the construction site. One plus factor is the exceptionally favourable weight distribution. It makes for enormous driving stability and ensures outstanding traction, even in rough terrain.



Another aspect becomes apparent when compacting uneven ground. Here, the articulated joint guarantees unrivalled driving comfort because it absorbs shocks extremely effectively.



In addition, any tendency of tipping in curves is greatly reduced – an important safety factor. And last but not least, the 3-point articulation enables outstanding directional stability.



QUICKLY DONE: DAILY MAINTENANCE



Xe lu Hamm 311P



The few maintenance tasks on soil compactors 311D are quickly done because the wellilluminated engine compartment is very low, making it readily accessible for the workshop technicians. The engine hood provides another benefit: thanks to the cleverly selected position of the pivot point, it can be opened wide, even in restricted headroom situations. Moreover, all maintenance points and the battery are easily accessible on one side of the machine.



Solutions for value retention



WIDOS (optional)



WIDOS covers the complete spare parts catalogue, all instructions, hydraulic, electrical and hose system plans, machine data and documentation, safety instructions, component pictures and service documentation in numerous languages - on paper and CD.



PERFECT OVERVIEW



Xe lu Hamm 311P



Hamm 311D offers ergonomically optimised workspaces as standard. They allow roller drivers to work with total concentration for many hours at a stretch.



Outstanding visibility



In addition, there is superb all-round visibility. This gives the driver a clear view of the drum at all times. The tyres and the space behind the roller are also fully visible because the engine hood has a slimline, sloping shape and the exhaust pipe is positioned so as not to interfere with the all-round view.



- Unobstructed view to the rear with no intrusive exhaust pipe.



- Unobstructed view of the drum.



- Comfortable driver’s seat, individually adjustable for height.



Ergonomically optimised and comfortable



Hamm compactor 311D offer operators plenty of space because every model has a large operator’s platform, accessible from one side. Another practical and comfortable feature is the driver’s seat, which can be moved forwards and backwards. Here, every driver is sure to find his ideal working position.



Xe lu Hamm 311P



Clear cockpit overview



In terms of operation, drivers of 311D compactors have it really easy: everything is clearly laid-out and self-explanatory.



Drive control is via two drive levers. The activation switch for the vibration is also located on the drive lever, so that the two most frequently used functions can be controlled with one hand. The dashboard is notable for its unambiguous, internationally understandable marking and labelling. Here, HAMM has dispensed with language, using clear symbols instead. As a result, these compactors can be operated entirely without language skills and yet always with comprehensive information on the current operating status of the machine - an important prerequisite for high-quality ground compaction.



TECHNOLOGIES



3-POINT ARTICULATTION



3-point articulation is different to conventional joints due to its geometric arrangement and connection of the three individual joints and one additional connecting link between the two conventional upper joints. This allows optimum steering, excellent driving safety and maximum driving comfort.



công nghệ khớp nối 3 điểm



See more at: HERE
